OIL FILTER/PUMP ASSEMBLY
1997 2X4
| # | Part No. | Description | Qty | Price | |
|---|---|---|---|---|---|
| 1 | 3402-153 | PUMP ASSY, ENGINE OIL | 1 | $255.95 | |
| 2 | 3402-152 | GEAR, OIL PUMP DRIVEN | 1 | $109.95 | |
| 3 | 3423-046 | PIN ,M4X15.8 | 1 | $3.30 | |
| 4 | 3423-115 | WASHER, PUMP DRIVEN GEAR THR-M10X18 | 1 | $2.06 | |
| 5 | 3423-871 | CIRCLIP | 1 | $3.71 | |
| 6 | 3423-867 | SCREW | 1 | $2.61 | |
| 7 | 3402-156 | STRAINER, OIL | 1 | $20.63 | |
| 8 | 1691-164 | SCREW,M5X12 | 1 | $3.44 | |
| 9 | 3402-157 | CAP, OIL STRAINER | 1 | $64.95 | |
| 10 | 3423-077 | O RING | 1 | $26.95 | |
| 11 | 3007-369 | BOLT,CYLINDER HEAD COVER NO. 1 | 1 | $3.16 | |
| 12 | 0812-034 | FILTER,OIL-(0812-029) | 1 | $16.49 | |
| 13 | 3403-021 | PLUG,DRAIN | 1 | $13.73 | |
| 14 | 3402-012 | GASKET, OIL PLUG,M13.8X18.8X0.4 | 1 | $10.97 | |
| 15 | 3402-154 | REGULATOR ASSY, OIL | 1 | $118.95 | |
| 16 | 3403-219 | UNION,OIL STAND | 1 | $20.63 |
